Shining 3D Einstar Vega, 3D skener
Shining 3D Einstar Vega, 3D skener
Shining3D Einstar Vega is a next-generation compact handheld 3D scanner with 0.05 mm accuracy and speed up to 1,500,000 points/s. It offers exceptional detail resolution of 0.1 mm for medium-sized objects and supports both wireless and wired operation.
✔️ 0.05 mm accuracy with 0.1 mm resolution
✔️ Speed of 1,500,000 points/s
✔️ Color textures with RGB camera
✔️ Wireless and wired operation
✔️ Compact 700 g design for comfortable scanning Show more
Shining3D Einstar Vega is a next-generation compact handheld 3D scanner with 0.05 mm accuracy and speed up to 1,500,000 points/s. It offers exceptional detail resolution of 0.1 mm for medium-sized objects and supports both wireless and wired operation.
✔️ 0.05 mm accuracy with 0.1 mm resolution
✔️ Speed of 1,500,000 points/s
✔️ Color textures with RGB camera
✔️ Wireless and wired operation
✔️ Compact 700 g design for comfortable scanning Show more
🌟
Next-generation Einstar
Einstar Vega takes the popular Einstar line to a new level. Significantly higher accuracy, faster sensors and improved EXScan Pro software make the Vega a true professional tool.
🎯
0.05 mm accuracy
Vega achieves its accuracy through a combination of structured light and advanced position tracking. Ideal for industrial parts, artwork and architectural fragments.
📡
Wireless freedom
An integrated battery and Wi-Fi connection let you scan cable-free anywhere. Just launch EXScan Pro on your computer and Vega streams data in real time.
🖼️
Vivid color textures
The RGB camera captures surface colors in sync with geometry. The resulting model is realistic and ready for visualization, game engines or 3D printing.
💡 Our tip
Scanning glossy, transparent or dark surfaces? Use a scanning spray – a temporary matte coating that eliminates reflections and evaporates after scanning. No cleanup, no residue.
| Parameter | Value |
|---|---|
| Technologie | Strukturované bílé světlo |
| Přesnost | 0,05 mm |
| Rozlišení bodu | 0,1 mm |
| Rychlost | 1 500 000 bodů/s |
| Textura | RGB kamera |
| Skenovaný objem | 0,3 m × 0,3 m – 2 m |
| Připojení | Wi-Fi / USB-C |
| Hmotnost | 700 g |
| Software | EXScan Pro |
| Export | OBJ, STL, PLY, ASC |
