Product Description

Fiberon™ PA6-CF20 is a technical filament based on Nylon 6 (PA6), reinforced with carbon fibers to significantly enhance its mechanical properties. It combines high strength, stiffness, and heat resistance with excellent layer adhesion, making it ideal for functional and mechanically stressed parts.

Compared to standard PA6, PA6-CF20 offers improved dimensional stability, greater resistance to deformation, and longer service life in demanding environments. This material is well-suited for producing mechanical components, structural parts, brackets, fixtures, and components exposed to heat and mechanical loads.

Proper printing requires the use of an all-metal hotend capable of reaching at least 280 °C and a hardened nozzledue to the abrasive nature of carbon fibers. The filament is moisture-sensitive – drying before printing, followed by annealing and moisture conditioning, significantly improves final performance and durability.

Key Features:

• 20% carbon fiber for high strength and stiffness

• good heat resistance

• excellent layer adhesion

• improved dimensional stability

• material density: 1.17 g/cm³

Printing Recommendations:

• all-metal hotend

• nozzle temperature: ≥ 280 °C

• hardened nozzle required

• dry filament before printing

• annealing and conditioning after printing

Typical Applications:

• mechanically stressed parts

• structural and functional components

• industrial fixtures and brackets

• parts exposed to heat and load
